Los sistemas generan una enorme cantidad de calor, sin embargo, y eso es lo único que puede poner en peligro su estabilidad. Reconociendo un mercado emergente, Data Aire unido sus fuerzas con los diseñadores de computadoras que llevan a desarrollar lo que se ha convertido en una línea de renombre mundial de productos de refrigeración de precisión.
Con las unidades montadas en el piso, las unidades montadas en el techo, unidades especializadas, intercambiadores de calor y controles de sistemas, Aire Data se compromete a permanecer en la vanguardia tecnológica de refrigeración de misión crítica.
Sólo 24 centímetros de alto, y está diseñado para entornos donde está limitado el espacio de piso, de techo unidades proporcionan opciones de instalación extremadamente flexibles. Split sistemas o envasados están disponibles con capacidades de hasta 13 toneladas para las grandes necesidades de refrigeración y de alimentación / retorno puede ser directo o conductos
When floor space is at a minimum but larger amounts of cooling are required, the LCS™ design fits the bill. DX units have either single or dual circuits. Air cooled units have either remote outdoor condensers or condensing units. Designed for draw through application, the computer-selected coil offers greater efficiency in the cooling and dehumidification process. Air bypass is provided to prevent saturated air from being introduced into the controlled space. LCS are shipped with the Mini Data Alarm Processor-II, a microprocessor controller.
All ceiling systems come with either R-410a or R-407c.
The Mini-Plus Ceiling is designed for environments where floor space is at a premium. Engineered to be ducted above ceiling applications, the Mini-Plus is available in a wide range of system configurations and functions with independence from other building air conditioning and ventilation systems. Air-cooled systems are either packaged or split type. Split systems may be ordered with indoor or outdoor condensers and condensing units. Standard units are shipped with a thermostat and sub-base for remote wall mounting. The Mini Data Alarm Processor-II is available as a wall-mounted option. All ceiling systems come with either R-410a or R-407c.
The Mini Ceiling is the perfect environmental control system for small computer centers, electronic, telephone, and battery rooms, or wherever spot cooling may be necessary and space is a problem. Designed with a vertical supply and return plenum that fits a 2 ft x 4 ft standard T-bar, the Mini Ceiling offers an unsurpassed combination of features and options along with a high standard of performance.
Mini Ceiling Systems are available as air-cooled, water cooled, or chilled water systems with a variety of return and supply air arrangements. Air cooled can be specified as packaged indoor units or split systems with either remote outdoor condensers or condensing units.
Los controles del sistema de datos por Aire son capaces de supervisar precisamente una o más unidades de aire acondicionado. Estos controles programados fácilmente proporcionar la máxima flexibilidad en la definición de la operación del sistema total. Con la adición de una tarjeta de comunicación, que puede ser instalado en la fábrica
When floor space is at a minimum but larger amounts of cooling are required, the LCS™ design fits the bill. DX units have either single or dual circuits. Air cooled units have either remote outdoor condensers or condensing units. Designed for draw through application, the computer-selected coil offers greater efficiency in the cooling and dehumidification process. Air bypass is provided to prevent saturated air from being introduced into the controlled space. LCS are shipped with the Mini Data Alarm Processor-II, a microprocessor controller.
All ceiling systems come with either R-410a or R-407c.
The DAP III is a self-contained multi-microprocessor based control and monitor system. It features flash memory and a USB port – allowing quick updates or modifications to firmware. DAP III was developed on a modular design platform with the basic components being the Display Module and Control Module
The Display Module features two rows of 40 character liquid crystal display for easy programming and diagnostic functions. It also houses the optional communications card, allowing communication with most major building management systems (BMS). The Control Module is mounted on the unit and connected using a CAT-5 cable. These two modules comprise the most basic control system, the Mini DAP III, which is an option on all Data Aire ceiling mounted systems.
The Data Alarm Processor-II (DAP-II) is the earlier, legacy version of the now standard Data Alarm Processor III, and was included on all floor-mounted units for over ten years prior to the introduction of the DAP III in late 2008. It was also an option for ceiling-mounted units during that same period of time.
The Mini Data Alarm Processor-II is a, one row, 16 character control that not only monitors the controlled environment’s humidity, air flow, and cleanliness, but also provides alarm history and an automatic self-test of the microprocessor on system start-up. Multiple messages are displayed by scrolling from each message to the next. All messages are presented on the liquid crystal display (LCD). Multiple alarms are displayed sequentially in order of occurrence. In addition, the Mini Data Alarm Processor-II has an inclusive seven day programming format for unoccupied or low demand periods. This secondary schedule can minimize equipment runtimes, reducing energy consumption and provide cost savings
